Advanced Class D Technology
Gangster’s advanced Class D technology can realize high efficiency of more than 90%, leads to lower power consumption and less heat. In practice this is crucial, since many amplifiers shut down because of accumulated heat. Our Class D amplifiers comes in smaller size with lighter weight, providing advantages both for installation and touring.
- Lower power consumption
- Less heat
- Smaller size
- Lighter weight
Power Factor Correction (PFC)
Gangster’s new generation PFC design offers the following advantages:
- Allows amplifier to deliver full power even during fluctuations in mains power
- Highest power density – allows for superb bass performance
- Reduced required generator capacity
- Higher stability even in poor mains conditions, e.g. in remote areas
- Cooler operation
- Lower distortion
Full-Bridge SMPS design allows optimized current conversion and increases reliability.
Dynamic Rail Voltage Management (DRVM)
DRVM technology significantly reduces the difference between the output voltage and rails voltage enabled by a real-time voltage tracking system. DRVM incorporates feedback loops between the output signal and power supply. These feedback loops are used to dynamically modulate the rails voltage to dramatically improve efficiency and decrease heat dissipation.
Key Advantages:
- Reduced noise floor
- Improved load handling capabilities
- Reduced electromagnetic radiation
- Lower idle power consumption
IGBT Transistors
Insulated Gate Bipolar (IGBT) transistors in Gangster amplifiers contribute towards high reliability and efficiency.
Component Quality
Gangster amplifiers are built using only the very best Hi-Fi level chips and capacitors manufactured by world leaders in the respective domains.
| Fairchild Semiconductor | On Semiconductor |
 |  |
| Infineon Semiconductor | ST Semiconductor |
 |  |
Build Quality
Gangster Amplifiers enjoy various treatments and have to pass many quality assurance tests before they are ready for shipping:
- Anti-moisture, anti-corrosion and dust-proof treatment
- Glue sealing of connectors and components to secure them for transport
- Semi-finished product test before assembly
- 8 hours aging test
- 200 times of turning on/off
- Vibration test before packaging
- Comprehensive Audio Precision parameter test
Protection
Gangster amplifiers feature a comprehensive list of protection features which allow them to perform reliably even under the most extreme and demanding operating conditions.
Amplifier Models
You can choose between the models of the
- entry level B Series
- economy E Series
- high-end D Series.
B Series
Typical applications for Gangster B Series amplifiers are highs and mids. These amps come in a lightweight enclosure and yet provide the most beautiful sound and all the power you need.
B4.10: 4-Channel × 1000 W
| Rated Output Power | 4 × 600 W @ 8 Ω 4 × 1000 W @ 4 Ω |
| Frequency Response | 20 – 20000 Hz, ±0.5 dB |
| Signal-to-noise Ratio (SNR) | > 102 dB @ 20 – 20000 Hz, 8 Ω load, A-weighted |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | 250 |
| Crosstalk @ 1 kHz | -76 dB |
| Input Sensitivity | 20 dB, 23 dB, 26 dB, 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Male / Female |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Parallel |
| Product Dimensions | 482 × 250 × 44 mm (w × d × h) |
| Packing Size | 555 × 395 × 98 mm (w × d × h) |
| Net / Gross Weight | 5 kg / 6 kg |
E Series
The Gangster E Series amplifiers provide high power, clear sound and strong reliability at a lower price. They optimize the ratio between sound quality and budget.
E2.50: 2-Channel × 5000 W
| Rated Output Power | 2 × 3000 W @ 8 Ω 2 × 5000 W @ 4 Ω 2 × 7100 W @ 2 Ω 1 × 10000 W @ Bridge 8 Ω 1 × 11000 W @ Bridge 4 Ω |
| Frequency Response | 20 – 20000 Hz, +0 / -1 dB |
| Signal-to-noise Ratio (SNR) | > 110 dB |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | > 5000 @ 20 – 200 Hz |
| Slew Rate | 50 V/μs @ 8 Ω |
| Crosstalk | -75 dB |
| Input Sensitivity | 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Female XLR |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Mono |
| Product Dimensions | 482 × 443 × 44 mm (w × d × h) |
| Packing Size | 615 × 615 × 119 mm (w × d × h) |
| Net / Gross Weight | 15 kg / 17 kg |
E4.27: 4-Channel × 2200 W
| Rated Output Power | 4 × 2200 W @ 2 Ω |
| Frequency Response | 20 – 20000 Hz, +0 / -1 dB |
| Signal-to-noise Ratio (SNR) | > 110 dB |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | > 5000 @ 20 – 200 Hz |
| Slew Rate | 50 V/μs @ 8 Ω |
| Crosstalk | -75 dB |
| Input Sensitivity | 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Female XLR |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Mono |
| Product Dimensions | 482 × 443 × 44 mm (w × d × h) |
| Packing Size | 615 × 615 × 119 mm (w × d × h) |
| Net / Gross Weight | 15 kg / 17 kg |
D Series
The Gangster Power Amplifiers of the D Series provide the highest power, clearest sound and strongest reliability you can get. Fully stable at 2 Ω. Made for music lovers seeking for the optimal sound experience.
D2.65: 2-Channel × 6500 W
| Rated Output Power | 2 × 3500 W @ 8 Ω 2 × 6500 W @ 4 Ω 2 × 7500 W @ 2 Ω 1 × 13000 W @ Bridge 8 Ω 1 × 15000 W @ Bridge 4 Ω |
| Frequency Response | 20 – 20000 Hz, +0 / -1 dB |
| Signal-to-noise Ratio (SNR) | > 110 dB |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | > 5000 @ 20 – 200 Hz |
| Slew Rate | 50 V/μs @ 8 Ω |
| Crosstalk | -75 dB |
| Input Sensitivity | 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Male & Female XLR |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Mono |
| Product Dimensions | 482 × 443 × 44 mm (w × d × h) |
| Packing Size | 615 × 615 × 119 mm (w × d × h) |
| Net / Gross Weight | 11 kg / 13 kg |
D4.17: 4-Channel × 1700 W
| Rated Output Power | 4 × 1000 W @ 8 Ω 4 × 1700 W @ 4 Ω 4 × 2900 W @ 2 Ω 2 × 3400 W @ Bridge 8 Ω 2 × 5800 W @ Bridge 4 Ω |
| Frequency Response | 20 – 20000 Hz, +0 / -1 dB |
| Signal-to-noise Ratio (SNR) | > 110 dB |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | > 5000 @ 20 – 200 Hz |
| Slew Rate | 50 V/μs @ 8 Ω |
| Crosstalk | -75 dB |
| Input Sensitivity | 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Female XLR |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Mono |
| Product Dimensions | 482 × 443 × 44 mm (w × d × h) |
| Packing Size | 615 × 615 × 119 mm (w × d × h) |
| Net / Gross Weight | 12 kg / 14 kg |
D4.36: 4-Channel × 3600 W
| Rated Output Power | 4 × 2000 W @ 8 Ω 4 × 3600 W @ 4 Ω 4 × 4500 W @ 2 Ω 2 × 7200 W @ Bridge 8 Ω 2 × 9000 W @ Bridge 4 Ω |
| Frequency Response | 20 – 20000 Hz, +0 / -1 dB |
| Signal-to-noise Ratio (SNR) | > 110 dB |
| Total Harmonic Distortion + Noise (THD+N) | < 0,05 %, 20 – 20000 Hz |
| Damping Factor | > 5000 @ 20 – 200 Hz |
| Slew Rate | 50 V/μs @ 8 Ω |
| Crosstalk | -75 dB |
| Input Sensitivity | 32 dB, 35 dB, 38 dB, 41 dB |
| Power Supply | AC 100 – 240 V, 50 / 60 Hz |
| Input Sockets | Female XLR |
| Output Sockets | Speakon |
| Mode Selections | Stereo / Bridge / Mono |
| Product Dimensions | 482 × 443 × 44 mm (w × d × h) |
| Packing Size | 615 × 615 × 119 mm (w × d × h) |
| Net / Gross Weight | 12 kg / 14 kg |
Monsters
Monsters description
Monster 3
Monster 3 description
